More information about the product V-belt 90.5″La for Husqvarna 38″ blade drive after 2005.
Outer length: La2292mm
Working length: Lw2274mm
Inner length: Li2240mm
Width: 12.5mm (1/2″)
Height: 9mm
Manufacturer: Mitsuboshi 13x2240Li
Replacement / Original No. -5321932-14 Blade drive: Brand Models / Type
CRAFTSMAN 917254690 HOP REN11597,REN12597 HUSQVARNA LT131, LT141, LT151, LTH141, LTH151 PARTNER P11597, P12597, P12597K POULAN PB14538LT, PB145G38, PO12538LT, PO14538LT, PO15538LT
How to measure a belt:
Outer circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure in an arc on the outside (with a tailor’s tape).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Inner circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt with a
Width of 10mm (3/8″) or 17mm (5/8″).
