Rebuild Kit With Standard Piston, Rod, Exhaust Valve For 5HP

MASTER rebuild for 5hp Briggs and Stratton
Piston with rings, connecting rod, gaskets and seals, intake valve
Fits models:
BRIGGS & STRATTON 130200, 130400, 131200, 132200, 132400, 133200, 135200, 135232 and 136200 5 HP Horizontal Engines
(Suffix does not matter; e.g., 130200 = 130202, 130204, etc.)
Kit includes:
Gasket Set (replaces B&S 495603) ?C for your model only
Oil Seal (replaces B&S 299819)
Oil Seal (replaces B&S 294606)
Exhaust Valve
Standard Connecting Rod (replaces B&S 299430)
Standard Piston Assembly (replaces B&S 298906) ?C includes piston, piston rings, wrist pin and wrist pin keepers
Torque specs provided.
Cylinder bore:
Standard: 2.5625″
+.010: 2.5725″
+.020: 2.5825″
Rod available in standard only.
