THIS ITEM FITS VARIOUS APPLICATIONS BY PART NUMBER. PLEASE CHECK YOUR PART NUMBER TO ENSURE FITMENT.
CLUB CAR GOLF CARTS DS SERIES 1984-2006
CLUB CAR GOLF CARTS FE290 1984-2006
CLUB CAR GOLF CARTS FE350 1984-2006
CLUB CAR UTV 1998-2002
JOHN DEERE UTV GATOR TX TURF KAWASAKI 15.5HP
FITS / Replacement Part Numbers:
CLUB CAR: 1018294-01 101833701 1036785-02
COLUMBIA PARCAR: 3008369A 30083-69B 3008369C 30083-69D 3008369E
HITACHI: 3102201HI1 GSB10701 GSB107-01A GSB10704A
HITACHI SALES: GSB107-04C
MANDO: G096503 G338771 M063686
REDHAWK: MOT2002 MOT-2004 MOT2005
ITEM DESCRIPTION: GENERATOR AND BRUSHES
UNIT TYPE: HITACHI, MANDO, VALEO
VOLTAGE: 12
AMPS: 25
BRUSH LENGTH: 1.024IN / 26MM
BRUSH WIDTH: 0.531IN / 13.5MM
BRUSH HEIGHT: 0.217IN / 5.5MM
LEAD LENGTH: 1.575IN / 40MM
BRUSH QUANTITY: 4
FIELD HSG OD: 113.3MM / 4.461IN
OVERALL LENGTH: 230.3MM / 9.067IN
ROTATION: CW
ROTATION: REVERSIBLE
SHAFT NOTES: THREADED WITH KEYWAY
SHAFT OD: 17MM / 0.669IN
TERMINAL 1 SIZE: M6-1.0
TERMINAL 2 SIZE: M5-0.8
TERMINAL 3 SIZE: M6-1.0
TERMINAL 4 SIZE: M6-1.0
NOTES: 5 TERMINAL MOTOR GENERATOR
WEIGHT: 18.5 LBS / 8.41 KG
