McCulloch M105-85F Drive V-Belt

SKU PD.13665 5763606-01,5354886-01 Category Tags ,

SPREAD THE LOVE

Description

More product information Drive V-Belt 4L440 McCulloch M105-85F, M105-97F, M125-85F, And Husqvarna ProFlex 21 AWD
Outer length: La1122mm
Working length: Lw1104mm
Inner length: Li1067mm
Width: 1/2″ (13mm)
Height: 7.5mm
Manufacturer: Kramp 4L440 FGP013432
Replacement / Original No. – 5763606-01,5354886-01
Application: Brand Models HUSQVARNA Gearbox-engine drive:PR18 AWD, ProFlex 21 AWD MCCULLOCH Travel drive:M105-85F, M105-97F, M125-85F
How to measure a belt:
Outer circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure in an arc on the outside (with a tailor’s tape).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a tape measure).
Inner circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a 10mm wide belt (3/8″) or 17mm (5/8″).
