More information about the product V-belt from engine to variator for Husqvarna Rider.
Outer length: La1474mm
Working length: Lw1460mm
Inner length: Li1422mm
Width: 12.6mm (1/2″)
Height: 8mm
Manufacturer: Optibelt LG2000054
Replacement / Original No. -5444002-01
Application: Brand Models / Type
HUSQVARNA R13C, R15T, R15Ts AWD, R214, R216, R316, R318, R320 AWD, Rider 175 AWD, Rider 18 AWD, Rider 220T, Rider 322T, Rider R11C JONSERED FR2111M, FR2211M, FR2213MA, FR2216A2, FR2218FA
How to measure a belt:
Outer circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure in an arc on the outside (with a tailor’s tape).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Inner circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt with a
Width of 10mm (3/8″) or 17mm (5/8″).
