More product information V-belt 33″La
Outer length: La845mm
Working length:Lw827mm
Inside length: Li787mm
Width:13mm (1/2″)
Height: 7.5mm
Manufacturer: KrampFGP013421 4L330
Application: Brand Replacement /
No. original Models/Type
HUSQVARNA 5069549-01,5069883-01 R15T, Rider 13, Rider 15, Rider 16, Rider 18, Rider 155, Rider 175, Rider 850, Rider 970,R13C, R15T, R214, R214TC, R216, R316, R318, R320 AWD, Rider 220T, Rider 322T, Rider R11C
How to measure a belt:
Outer Circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure with an arc on the outside (with a tailor’s tape measure).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Internal circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt that is 10mm (3/8″) or 17mm (5/8″) wide.
