Husqvarna CTH160 V-belt

SKU PD.13659 5321656-32,5310075-49 Category Tags ,

SPREAD THE LOVE

Description

More product information A112 travel drive v-belt for Husqvarna, Partner, McCulloch tractors, with 92cm and 107cm (36 and 42″) cutting
Widths with Hydro-Gear Model 331-0650 gearbox.
Outer length: LA2850mm
Working length: Lw2830mm
Inner length: Li2795mm
Width: 12.7mm. 1/2”
Height: 8mm
Manufacturer: Kramp FGP013402
Replacement / Original No. – 5321656-32, 5310075-49
Application: BRAND MODEL AYP / ROPER GS14536HA, RER145H36C HUSQVARNA CTH160 (99), CTH160 II (01), CTH130 (01), CTH150 May fit older CT160 models with manual transmission, some CT160 models may have a shorter belt – see OG1782
How to measure a belt:
Outer Circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure with an arc on the outside (with a tailor’s tape measure).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Internal circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt that is 10mm (3/8″) or 17mm (5/8″) wide.
